Canon XF605 Specs
| Sensor Resolution | Actual: 13.4 Megapixel (4268 x 3148) Effective: 8.29 Megapixel (3840 x 2160) |
| Image Sensor | 1"-Type CMOS |
| Image Stabilization | Optical in Integrated Lens Digital |
| Built-In ND Filter | Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters |
| Capture Type | Stills & Video |
| Shutter Type | Electronic Rolling Shutter |
| Shutter Speed | 1/2000 to 1/4 Second |
| Shutter Angle | 11 to 360° |
| Sensitivity | f/12 at 2000 lux |
| Minimum Illumination | 1.5 Lux at 1/30 Shutter Speed |
| White Balance | 2000 to 15,000K |
| Focal Length | 8.3 to 124.5mm (35mm Equivalent Focal Length: 25.5 to 382.5mm) |
| Optical Zoom Ratio | 15x |
| Max Digital Zoom | 30x ( in 1080p) |
| Maximum Aperture | f/2.8 |
| Minimum Aperture | f/4.5 |
| Optical Design | 18 Elements in 14 Groups |
| Minimum Focus Distance | Entire Zoom Range: 2.0' / 60.0 cm Wide: 0.4" / 1.0 cm |
| Filter Size | 58 mm |
| Control Rings | Focus Zoom Iris |
| Focus Control | Autofocus Manual Focus |
| Internal Recording Modes | MXF/XF-AVC 4:2:2 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s] 1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps H.265/MP4 4:2:2 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s] H.265/MP4 4:2:0 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s] H.264/MP4 4:2:0 8-Bit 3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s] 1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps |
| External Recording Modes | SDI/BNC UHD 4K (3840 x 2160) up to 59.94 fps |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve | Canon Log 3, HDR-HLG |
| Built-In Microphone Type | Stereo |
| Audio Recording | 2-Channel 16-Bit 48 kHz AAC Audio 4-Channel 24-Bit 48 kHz LPCM Audio |
| IP Streaming | MPEG2 1920 x 1080 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.0 Mb/s) 1920 x 1080 at 50i, 59.94i (4.0 to 9.0 Mb/s) |
| Media/Memory Card Slot | Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC |
| Video I/O | 1 x HDMI 2.0 Output 1 x BNC (12G-SDI) Output |
| Audio I/O | 2 x XLR 3-Pin Input 1 x 1/8" / 3.5 mm TRS Stereo Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1 x Barrel (24VDC) Input |
| Other I/O | 1 x USB-A Output 1 x USB-C 1 x BNC (Genlock, Sync) Input/Output 1 x BNC (Timecode) Input/Output 1 x 2.5 mm Sub-Mini Control 1 x D-Sub 8-Pin Control 1 x RJ45 (LAN) Input/Output |
| Wireless | 2.4 / 5 GHz MIMO Wi-Fi Video Output, Audio Output, Control |
| Global Positioning (GPS, GLONASS, etc.) | None |
| Size | 3.45" |
| Resolution | 2,760,000 Dot |
| Display Type | Articulating Touchscreen LCD |
| Type | Removable Electronic (OLED) |
| Size | 0.36" |
| Resolution | 1,770,000 Dot |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Automatic, Manual Focus |
| Operating Temperature | 32.0 to 104.0°F / 0.0 to 40.0°C |
| Operating Humidity | 0 to 85% |
| Battery Type | Canon BP-A Series |
| Power Consumption | 21.5 W |
| Tripod Mounting Thread | 1/4"-20 Female 3/8"-16 Female |
| Accessory Mount | 1 x Cold Shoe Mount 1 x Intelligent Hot Shoe |
| Built-In Video Light | Yes (Infrared) |
| Dimensions (W x H x D) | 15.2 x 8.6 x 8.3" / 385 x 219 x 210 mm (With Protrusions) 13.1 x 6.8 x 6.6" / 333 x 173 x 168 mm (Without Protrusions) |
| Weight | 4.4 lb / 2010 g |
